from $ 65 USD
includes
up to 3 years of Loc8 service,
and own branded software/apps
|
|
|
4G QT LTE
350 Series GPS Trackers
|
ABOUT
TRACKERS
|
|
Sinopacifics range of 4G QT
LTE trackers have been designed and developed to allow for a wide range of versatile features and functions.
Sinopacifics 4G QT LTE trackers can be used with the QProtect, Loc8, Track and Watch product offerings.
|
TECHNICAL
PARAMETERS
|
|
|
|
Tracker
|
|
|
|
Size
|
79*38*16mm
|
70.8*41.8*30mm
|
|
Weight
|
43.2g (Including
battery)
|
106g
|
|
Operating temperature
|
-20°C to +60°C
|
-20°C to +60°C
|
|
Storage temperature
|
-20°C to +70°C
|
-20°C to +70°C
|
|
Sensor
|
Precision vibration
sensor
|
Precision vibration
sensor
|
|
Bands
|
B1/B2/B3/B4/B5/B7/B28
B66; GSM/GPRS 850/900
1800/1900MHz
|
B1/B2/B3/B4/B5/B7/B28
B66; GSM/GPRS 850/900
1800/1900MHz
|
|
Max
Frequency Error
|
±0.1ppm
|
±0.1ppm
|
|
Receiver sensitivity
|
-107dbm
|
-107dbm
|
|
Dynamic output range
|
-15~-108dbm
|
-15~-108dbm
|
|
Sensitivity
|
Cold start: -145 dbm;
Warm start: -156 dbm;
Navigation: -160 dbm;
Track: -162 dbm
|
Cold start: -145 dbm;
Warm start: -156 dbm;
Navigation: -160 dbm;
Track: -162 dbm
|
|
Antenna
|
GSM and GPS antenna
internal only
|
Built-in GPS/BD
dual-mode
18*18*2mm
|
|
Position Accuracy
|
<5m< /font>
|
WIFI <5m, GPS
<10m
|
|
Communication chip
|
SIMCOM-A7670C
|
SIMCOM-A7670C
|
|
Time
to first fix
|
Cold start: An avg of
32 sec
|
Cold start: An avg of
38 sec
|
|
Root-Mean-Square
Error
|
S degree
|
S degree
|
|
|
|
|
Tracker
|
|
|
|
Size
|
46*25*32mm
|
82.9*49.5*36mm
|
|
Weight
|
35g (Including battery)
|
40g (include battery)
|
|
Operating temperature
|
-20°C to +60°C
|
-20°C to +60°C
|
|
Storage temperature
|
-20°C to +70°C
|
-20°C to +70°C
|
|
Sensor
|
Precision vibration
sensor
|
Precision vibration
sensor
|
|
Bands
|
B1/B2/B3/B4/B5/B7/B28
B66; GSM/GPRS 850/900
1800/1900MHz
|
B1/B2/B3/B4/B5/B7/B28
B66; GSM/GPRS 850/900
1800/1900MHz
|
|
Max
Frequency Error
|
±0.1ppm
|
±0.1ppm
|
|
Receiver sensitivity
|
-107dbm
|
-107dbm
|
|
Dynamic output range
|
-15~-108dbm
|
-15~-108dbm
|
|
Sensitivity
|
Cold start: -145 dbm;
Warm start: -156 dbm;
Navigation: -160 dbm;
Track: -162 dbm
|
Cold start: -145 dbm;
Warm start: -156 dbm;
Navigation: -160 dbm;
Track: -162 dbm
|
|
Antenna
|
GSM and GPS antenna
internal only
|
GSM and GPS antenna
internal only
|
|
Position Accuracy
|
<5m< /font>
|
<5m
|
|
Communication chip
|
SIMCOM-A7670C
|
SIMCOM-A7670C
|
|
Time
to first fix
|
Cold start: An avg of
32 sec
|
Cold start: An avg of
32 sec
|
|
Root-Mean-Square
Error
|
S degree
|
S degree
|
|
|
